Left, Right, Input ground, output ground comprises the four channels architecture.
Our design eliminates ground current interference, which improves the sound purity.
Nichicon FW audio aluminum electrolytic capacitors are used as the power filter capacitors.
The use of five high speed operation amplifiers provide substantial output power.
Current feedback buffers are used that provide a high bandwidth, exceptional slew rate, impactful dynamics, excellent transprancy and a blacker background.
การรับประกัน : 1 เดือน
อุปกรณ์ภายในกล่อง
ข้อมูลจำเพาะ
3.5mm Phone out:
Max Output: 3.2Vrms
Frequency response: 20Hz-20KHz-0.ldB
SN: 117dB
THD+N:0.00056%,-105dB(32Ω@1.8Vrms),[email protected] without load.
DNR: 117dB
Crosstalk: -109dB
Line out:
Frequency Response: 20Hz-20 KHz-0.ldB
SN: 118dB
THD+N :< 0.00018%, -115dB
